External control wall washer controller installation wiring instructions:
High-power LED wall washers can be installed in a single installation or in combination with multiple lamps. What kind of phenomenon will occur when installing wall washers? Unreasonable installation of controller wiring can cause all fixtures to illuminate. Shenzhen SH LED Technology Co., Ltd lighting wall washer manufacturers explain how to properly install the external wall washers.
Wiring instructions for external control LED wall washer controller:
The controller information line is a three-core cable, A1 is connected to blue, B1 is connected to green, red is connected to GND, and the signal must be input from the male of the LED wall washer. The female is out, the power is two-core, and the two-core is brown. Connect the positive pole of the switching power supply, and the blue is connected to the negative pole of the switching power supply.
LED wall washer use precautions:
1. Pay attention to shockproof during installation and transportation of LED wall washers.
2. Before installing the LED wall washer, ensure that the installation position can withstand 10 times the weight of the product. Installed in a place where there is no vibration, no sway, no fire hazard.
3. LED wall washers use a power supply that matches the standard on the product.
4. There are precision devices in the LED wall washer, please do not disassemble it.
5. If the LED wall washer fails, please return it for repair.
Wall washing installation process:
1. Do the pre-installation work according to the location where the power supply is placed;
2. Fix the fixture securely with screws;
3. Connect the lamp to the power cord firmly, and the unused wire ends are wrapped with waterproof tape;
4. When installing the wiring, a branch power supply can connect up to 8-10 wall washers in series; or 50 meters after another power cord;
5. After the installation is completed, please check the installation line to confirm that the installation is correct. If there is no electrical short circuit, turn on the corresponding control power.
